Fortinet NSE5_FSW_AD-7.6 Exam Practice Questions
US$39
Every question with the correct answer and why the other options are wrong.
Card, Apple Pay, Google Pay or PayPal. Download links are on your order page and in your email the moment you pay.
Passed!!! Wonderful Fortinet NSE5_FSW_AD-7.6 exam study materials.
Three of the 64 questions in this pack
Question 1
Which two are valid traffic processing actions that a FortiSwitch access control list (ACL) can apply to matching traffic? (Choose two.)
Show answer and explanation
Correct answer: A, D. Redirect frames to another port; Drop frames.
A FortiSwitch ACL matches traffic using classifier fields such as MAC addresses, IP addresses, VLAN, protocol and ports, and then applies an action to the matching frames in hardware. Two of the core forwarding actions are drop, which discards the matching frames so they never leave the switch, and redirect, which sends the matching frames out of a specified port instead of following the normal forwarding path. Both act directly on where the frame goes, and both are performed at wire speed by the switch ASIC without involving the CPU.
Why the other options are wrong
- B. Placing traffic into a high-priority egress queue is a QoS treatment that changes how a frame is scheduled, not a traffic processing action that decides where the frame goes.
- C. FortiSwitch ACLs operate on frame headers in the switching ASIC and have no ability to encrypt frames.
Question 2
Which two statements about 802.1X authentication on FortiSwitch ports are true? (Choose two.)
Show answer and explanation
Correct answer: A, B. In port-based 802.1X, all hosts behind an authenticated port are allowed access after a successful authentication; A port policy is used to apply 802.1X authentication on a FortiSwitch interface.
FortiSwitch supports port-based and MAC-based 802.1X security modes. In port-based mode, the port is opened as soon as one supplicant authenticates successfully, and every host connected behind that port, for example through an unmanaged hub or switch, is then allowed access without authenticating individually. The authentication settings themselves are defined in a port security policy (user groups, guest VLAN, authentication fail VLAN, MAC authentication bypass and similar options), and that policy is then applied to the FortiSwitch interface to enforce 802.1X on it. These two statements describe how 802.1X is deployed on FortiSwitch ports.
Why the other options are wrong
- C. 802.1X is normally applied to access ports where end devices connect; it is not limited to trunk ports.
- D. Devices without 802.1X support can still connect through options such as MAC authentication bypass or a guest VLAN.
Question 3
What happens if FortiSwitch fails to discover either FortiEdge Cloud or a FortiGate with FortiLink?
Show answer and explanation
Correct answer: B. It remains in local management mode.
A FortiSwitch can be managed by FortiGate through FortiLink, by FortiEdge Cloud, or locally as a standalone switch. When it boots, it looks for a management platform. If it does not discover either FortiEdge Cloud or a FortiGate with FortiLink, nothing takes over control of the switch, so it simply continues to operate in local management mode. The administrator can then manage it through its own GUI or CLI, and it can still be brought under FortiGate or cloud management later once one of those becomes reachable.
Why the other options are wrong
- A. FortiLink management requires a discovered FortiGate, so failing to find one cannot place the switch under FortiLink control.
- C. A failed discovery does not damage the firmware or configuration, so no reimaging is needed.
- D. Discovery failure does not cause the switch to turn off its auto-network setting.
2 reviews for Fortinet NSE5_FSW_AD-7.6 Exam Practice Questions
Only logged in customers who have purchased this product may leave a review.
How much of the Fortinet NSE5_FSW_AD-7.6 bank is free?
64 questions in the bankEach step includes the one before, so buying only adds new questions.
- You are here10questionsFree sampleThree on this page, all ten as a PDF.Download the sample
- 1625% of the bankPractice pageFree on the site, every answer explained.Go to the practice page
- 32the first half of the packHalf PackFree by email, as one PDF, every answer explained.Get the Half Pack
- 64100%, the whole bankFull pack, US$39Plus the questions-only PDF, monthly updates, refund if you fail.Get the full pack
What’s in the Fortinet NSE5_FSW_AD-7.6 pack
- 64 questions mapped to the NSE5_FSW_AD-7.6 exam description
- Answers and explanations for every question, including the wrong options
- A questions-only PDF for timed practice runs
- Instant delivery by email the moment you check out
- Free monthly updates for as long as the exam is live
- Pass or your money back
A NSE5_FSW_AD-7.6 attempt costs US$200. This pack is US$39, paid once.
What makes the NSE 5 FortiSwitch exam hard
NSE5_FSW_AD-7.6 is the FortiSwitch exam under Fortinet's July 2026 rebranding, where the product-level exams took NSE 4, 5 and 6 numbering and the FCP Secure Networking track became the NSE 5 in Secure Networking certification. It evaluates applied knowledge of FortiSwitch on FortiSwitchOS 7.6 integrated with FortiOS 7.6, through supported deployment topologies, operational scenarios, configuration extracts and troubleshooting captures, with standalone mode tested alongside FortiLink management.
The exam is built around four areas: FortiSwitch concepts and management modes, deployment and management over FortiLink including MCLAG and tiered topologies, Layer 2 control and security covering VLANs, spanning tree, link aggregation, port security and 802.1X, and monitoring and troubleshooting with packet capture and the diagnose switch command set.
Candidates consistently report that the tagging and native VLAN questions and the CLI-output questions are where marks are lost, so it is worth practising reading physical-ports summaries before sitting it.
About the exam
NSE5_FSW_AD-7.6 (Fortinet NSE 5, FortiSwitch 7.6 Administrator) is a product exam counting towards the NSE 5 in Secure Networking certification. It covers FortiSwitch concepts and management modes, deployment and management over FortiLink, Layer 2 control and security, and monitoring and troubleshooting on FortiSwitchOS 7.6 with FortiOS 7.6. The certification requires the NSE 4 FortiOS certification, and Fortinet recommends the FortiSwitch course and hands-on experience.
Questions before you buy
How quickly do I receive it?
Straight away. The full PDF and a questions-only copy are emailed to you the moment your payment goes through, and the same links are on your order page.
Are updates included?
Yes. The pack is updated every month for as long as the exam is live, and updates are free for everyone who has bought it.
What if I fail the exam?
We refund the pack, or swap it for any other pack if you would rather keep studying. Sit the exam 7 to 30 days after buying, then send your official score report within 7 days of the exam date, as set out in the refund policy.
What is your pass rate?
99% of customers who prepare with a CertStash pack pass. If you do not, we refund the pack, or swap it for another pack.
Can I share it with colleagues?
Each purchase is licensed to one person. For a team, school or training organisation, email support@certstash.com for a licence that fits.
